YASKAWA安川基板YRC1000的機械安全基板JANCD-ASF01-E
YASKAWA安川基板YRC1000的機械安全基板JANCD-ASF01-E
YASKAWA安川基板YRC1000的機械安全基板JANCD-ASF01-E
YASKAWA安川基板YRC1000的機械安全基板JANCD-ASF01-E
歐姆龍NX系列安全控制器 (JANCD-ASF01-E)? 的深度技術解析，涵蓋安全功能架構、認證標準、系統集成及安全回路設計要點：
一、核心規格速查表
|
?參數?
|
?規格?
|
|
?型號?
|
JANCD-ASF01-E
|
|
?安全等級?
|
SIL3 (IEC 61508), PLe (ISO 13849)
|
|
?安全輸入點數?
|
16點 (雙通道)
|
|
?安全輸出點數?
|
8點 (半導體輸出)
|
|
?響應時間?
|
≤15ms (輸入→輸出)
|
|
?診斷覆蓋率?
|
99% (DCavg)
|
|
?工作電壓?
|
24V DC (±15%)
|
|
?通信接口?
|
EtherCAT FSoE (Safety over EtherCAT)
|
|
?MTTFd?
|
>100年 (具體值見安全手冊)
|
|
?工作溫度?
|
-10°C ~ +55°C
|
?? ?安全認證?：
-
TüV Rheinland: SIL3/PL e
-
UL 61800-5-2
-
CE (EMC/LVD)
二、安全功能架構
?硬件冗余設計?
graph LR
A[輸入信號] --> B(通道A處理器)
A --> C(通道B處理器)
B --> D[比較器]
C --> D
D --> E{一致性檢測}
E -->|通過| F[輸出驅動]
E -->|故障| G[安全狀態]
?安全功能模塊?
|
?功能碼?
|
?安全功能?
|
?符合標準?
|
|
SF01
|
緊急停止
|
ISO 13850
|
|
SF02
|
安全門鎖
|
ISO 14119
|
|
SF03
|
雙手控制
|
ISO 13851
|
|
SF04
|
安全限速
|
IEC 60204-1
|
