低插入損耗;高回波損耗;重復性好;互換性能好；環境適應性好。
產品類型Product type
|
ST
|
SC
|
FC
|
LC
|
MTRJ
|
可按客戶要求Available on request
|
|||||||||
PC
|
UPC
|
PC
|
UPC
|
APC
|
PC
|
UPC
|
APC
|
PC
|
UPC
|
APC
|
PC
|
||||
光纖類型Fiber type
|
9/125, SM G. 652
|
||||||||||||||
插入損耗Insert Loss
|
≤0.3dB,典型值(Typical Value)≤0.2dB
|
≤0.5dB
|
|||||||||||||
回波損耗Return Loss
|
≥45
|
≥50
|
≥45
|
≥50
|
≥65
|
≥45
|
≥50
|
≥65
|
≥45
|
≥50
|
≥65
|
≥45dB
|
|||
重復性Reduplication
|
≤0.1dB
|
||||||||||||||
互換性Interchange
|
≤0.2dB
|
||||||||||||||
工作溫度WorkTemperature
|
-25℃-+70℃
|
-40℃-+70℃
|
-25℃-+70℃
|
||||||||||||
插撥次數Insert＆Draw Time
|
>500次
|
||||||||||||||
訂貨長度More connectors
|
要求長度（Available on request）
|
||||||||||||||
產品類型Product type
|
ST
|
SC
|
FC
|
LC
|
MTRJ
|
可按客戶要求Available on request
|
||||||||
PC
|
UPC
|
PC
|
UPC
|
PC
|
UPC
|
PC
|
UPC
|
PC
|
||||||
光纖類型Fiber type
|
62.5/125, 50/125 萬兆光纖（Ethernet fiber）
|
|||||||||||||
插入損耗Insert Loss
|
≤0.3dB,典型值(Typical Value)≤0.2dB
|
≤0.5dB
|
||||||||||||
回波損耗Return Loss
|
≥30dB
|
|||||||||||||
重復性Reduplication
|
≤0.1dB
|
|||||||||||||
互換性Interchange
|
≤0.2dB
|
|||||||||||||
工作溫度WorkTemperature
|
-25℃～+70℃
|
-40℃～+70℃
|
-25℃～+70℃
|
|||||||||||
插撥次數Insert＆Draw Time
|
<500次
|
|||||||||||||
訂貨長度More connectors
|
要求長度（Available on request）
|
|||||||||||||
