德國JUMO GmbH & KG公司成立于1948年，位于德國中部城市Fulda。公司經過六十多年的發展，已經成為歐洲著名的儀表制造廠商，公司主要致力于生產高質量的傳感器、變送器及控制器，可提供工業溫度、壓力、濕度、液位、流量、pH值、電導率、氧化還原值的測量、控制及記錄產品。除了在德國Fulda的主要工廠外，JUMO在全球范圍內擁有二十三家子公司、四十多家代理商及銷售分支結構，在中國、美國、印度的分公司是JUMO國際化的象征。JUMO憑借多年的經驗及優秀的品質一直為自動化測量及控制工程領域的客戶提供著專業水準的產品和服務。
產品系列
| 1 | 517148 | 401010 |
401010/000-458-405-502-20-61/000 458 0-6bar |
| 2 | 517139 | 401010 |
401010/000-459-405-502-20-61/000 459 0-10bar |
| 3 | 517133 | 401010 |
401010/000-460-405-502-20-61/000 460 0-16bar |
| 4 | 523660 | 401010 |
401010/000-461-405-502-20-61/000 461 0-25bar |
| 5 | 527947 | 401010 |
401010/000-462-405-502-20-61/000 462 0-40bar |
| 6 | 43012531 | 401010 |
401010/000-463-405-502-20-61/000 463 0-60bar |
| 7 | 531799 | 405052 |
405052/000-461-475-613-20-36-01/000 b: 0..25 bar relative output: 1x PNP switching output + 4..20mA 3-wire process connect.:clamp nipple DN25/32/40 DIN 32676 mat. proc. conn.: CrNi (stainless steel) electric.connec.:circular connector M12x1 supply: DC12(14)..30V |
| 8 | 541189 | 405052 |
405052/000-454-475-613-20-36-01/000 b: 0..1 bar relative output:1x PNP switching output + 4..20mA 3-wire process connect.:clamp nipple DN25/32/40 DIN 32676 mat. proc. conn.: CrNi (stainless steel) electric.connec.:circular connector M12x1 supply: DC12(14)..30V |
| 9 | 595822 | 405052 |
405052/004-454-475-613-20-36-01/374,769 0..1 bar relative model : JUMO DELOS SI - for increased medium temperature up to 200°C b : 0..1 bar relative output : 1x PNP switching output and 1 analog output 4...20 mA, configurable process connection : clamp nipple DN25/32/40 DIN 32676 mat. process connec.: CrNi (stainless steel) electrical connect. : circular connector M12x1 filling medium : silicone oil extra code 374 : inspection certificate 3.1 EN 10204: material extra code 769 : with calibration certificate output scale SCL : 0,000 output scale SCH : 1,000 power supply : DC12(14)..30V Company logo : JUMO drawing number : General drawing Product is not intended for the export in the USA. |
| 10 | 595820 | 405052 |
405052/004-483-475-613-20-36-01/374,769 -1..9 bar relative model : JUMO DELOS SI - for increased medium temperature up to 200°C b : -1..9 bar relative output : 1x PNP switching output and 1 analog output 4...20 mA, configurable process connection : clamp nipple DN25/32/40 DIN 32676 mat. process connec.: CrNi (stainless steel) electrical connect. : circular connector M12x1 filling medium : silicone oil extra code 374 : inspection certificate 3.1 EN 10204: material extra code 769 : with calibration certificate output scale SCL : -1,000 output scale SCH : 9,000 power supply : DC12(14)..30V Company logo : JUMO drawing number : General drawing Product is not intended for the export in the USA. |
| 11 | 43001026 | 404366 |
404366/000-482-405-613-20-61/000 -1..5bar |
| 12 | 43009793 | 404366 |
404366/000-483-405-613-20-61/000 -1..9bar |
| 13 | 639291 | 402050 |
402050/000-457-405-613-20-61/631 0..4 bar rel |
| 14 | 595385 | 402050 |
402050/000-458-405-613-20-61/631 0..6 bar rel. model : JUMO dTRANS p31 pressure transmitter b : 0..6 bar relative output : 4..20mA 2-wire process connection : clamp nipple DN25/32/40 DIN 32676 mat. process connec.: CrNi (stainless steel) electrical connect. : connector for cable connection DIN EN 175301-803 b A extra code 631 : higher humidity + vibration protect. range start : 0,000 range end : 6,000 unit range : bar power supply : DC10..30V Company logo : JUMO |
| 15 | 595109 | 402050 |
402050/000-459-405-613-20-61/631 0..10 bar rel. model : JUMO dTRANS p31 pressure transmitter b : 0..10 bar relative output : 4..20mA 2-wire process connection : clamp nipple DN25/32/40 DIN 32676 mat. process connec.: CrNi (stainless steel) electrical connect. : connector for cable connection DIN EN 175301-803 b A extra code 631 : higher humidity + vibration protect. range start : 0,000 range end : 10,000 unit range : bar power supply : DC10..30V Company logo : JUMO |
| 16 | 639293 | 402050 |
402050/000-481-405-613-20-61/631 -1..3 bar rel. |
| 17 | 592294 | 402050 |
402050/000-482-405-613-20-61/631 -1..5 bar rel. model : JUMO dTRANS p31 pressure transmitter b : -1..5 bar relative output : 4..20mA 2-wire process connection : clamp nipple DN25/32/40 DIN 32676 mat. process connec.: CrNi (stainless steel) electrical connect. : connector for cable connection DIN EN 175301-803 b A extra code 631 : higher humidity + vibration protect. range start : -1,000 range end : 5,000 unit range : bar power supply : DC10..30V Company logo : JUMO |
| 18 | 639297 | 402050 |
402050/000-483-405-613-20-61/631 -1..9 bar rel. |
