| Mn | C | Si | Cr |
| 0.7 % | 0.67 % | 0.7 % | 10.4 % |
| Fusion time per electrode at 90% I max | kg weld bl/kg electrodes | Number of electrodes/kg weld bl | 安培 | 熔敷率 | 電壓 V | 直徑 |
| 62 sec | 0.67 kg | 58 | 75-110 A | 1.0 kg/h | 23 V | 2.5 x 350 mm |
| 95 sec | 0.67 kg | 27 | 110-150 A | 1.4 kg/h | 23 V | 3.2 x 450 mm |
| 107 sec | 0.67 kg | 18 | 145-200 A | 1.9 kg/h | 24 V | 4.0 x 450 mm |
| 110 sec | 0.66 kg | 12 | 190-270 A | 2.8 kg/h | 26 V | 5.0 x 450 mm |
| 分類(lèi): | E Z Fe6, EN 14700 |
| Coating Type: | Lime Basic |
| Welding Current: | AC, DC+ |
| 合金類(lèi)型: | Martensitic steel |
