| Mn | C | Si | Cr |
| 0.7 % | 0.1 % | 0.7 % | 3.2 % |
| Fusion time per electrode at 90% I max | kg weld bl/kg electrodes | Number of electrodes/kg weld bl | 安培 | 熔敷率 | 電壓 V | 直徑 |
| 75 sec | 0.64 kg | 69 | 60-90 A | 0.7 kg/h | 20 V | 2.5 x 350 mm |
| 88 sec | 0.66 kg | 34 | 100-140 A | 1.2 kg/h | 21 V | 3.2 x 450 mm |
| 92 sec | 0.66 kg | 23 | 140-190 A | 1.7 kg/h | 22 V | 4.0 x 450 mm |
| 86 sec | 0.68 kg | 15 | 190-260 A | 2.8 kg/h | 23 V | 5.0 x 450 mm |
| 92 sec | 0.68 kg | 11 | 230-320 A | 3.7 kg/h | 23 V | 6.0 x 450 mm |
| 認(rèn)證: | EN 13479, CE, 82.039.07, DB |
| 分類: | E Z Fe1, EN 14700 |
認(rèn)證均基于工廠的所在地。如需更多信息，請聯(lián)系伊薩。
| Coating Type: | Lime Basic |
| Welding Current: | AC, DC+ |
| 合金類型: | Martensitic steel |
