| As welded | |||
| 保護氣體 | 屈服強度 | 延伸率 | 抗拉強度 |
| ISO | 510 MPa | 32 % | 610 MPa |
| AWS | - | - | - |
| As welded | ||
| 保護氣體 | 沖擊值 | 測試溫度 |
| ISO | 50 J | 20 °C |
| ISO | 35 J | -20 °C |
| Mn | Mo | C | Si | Ferrite FN | Ni | N | Cr |
| 0.6 % | 2.8 % | 0.02 % | 0.8 % | 18 % | 13.4 % | 22.5 % |
| Fusion time per electrode at 90% I max | kg weld bl/kg electrodes | Number of electrodes/kg weld bl | 安培 | 熔敷率 | 電壓 V | 直徑 |
| 48 sec | 0.58 kg | 147 | 40-60 A | 0.6 kg/h | 26 V | 2.0 x 300 mm |
| 45 sec | 0.57 kg | 94 | 50-90 A | 0.9 kg/h | 29 V | 2.5 x 300 mm |
| 61 sec | 0.59 kg | 47 | 60-120 A | 1.4 kg/h | 27 V | 3.2 x 350 mm |
| 56 sec | 0.61 kg | 32 | 85-180 A | 2.0 kg/h | 31 V | 4.0 x 350 mm |
| 64 sec | 0.59 kg | 20 | 110-250 A | 2.7 kg/h | 30 V | 5.0 x 350 mm |
| 認證: | SS to C&C/Mn steels, ABS, 309Mo, BV, EN 13479, CE, CSA W48: E309LMo-17, CWB, 30.039.05, DB, VL 309 Mo, DNV-GL, SS/CMn, LR, 309Mo, RINA, UNA 272580, Seproz, 02424, VdTüV |
| 分類: | E 23 12 2 L R 3 2, EN ISO 3581-A, E309LMo-17, SFA/AWS A5.4, E309LMo-17, CSA W48, 1.4459, Werkstoffnummer |
認證均基于工廠的所在地。如需更多信息，請聯(lián)系伊薩。
| Coating Type: | Acid Rutile |
| Ferrite Content: | FN 12-22 |
| Welding Current: | DC+, AC |
| 合金類型: | Austenitic CrNi |
