主要特點
1、構造簡單，壽命長，適用性廣。
2、操作容易，檢修更換方便。
3、規格齊全，可根據水質指定材料。
安裝
1、安裝前首先檢查土建預留尺寸，特別是格柵導槽尺寸，應符合圖紙規定和要求。
2、貨物到現場后打開包裝箱，任何情況下不得野蠻開箱；然后檢查格柵在運輸過程中有無變形、損壞等予以調整糾正。
3、用鋼絲繩穿過格柵吊耳處，起吊過程中確保格柵與地面垂直，然后將格柵插入導槽內，檢查抽動是否靈活；并注意格柵的水流方向是從格柵指向海水吸收泵。
4、 將格柵插入導槽內，檢查抽動是否靈活。
5、安裝格柵的起落設備，檢查起落設備動作是否靈活可靠。
6、檢查無誤后，按圖紙尺寸用配套緊固件緊固或者焊接在預埋件上。
|
進水口 |
格柵 |
間隙C |
導軌 |
進水口 |
格柵 |
間隙 |
導軌 |
|
700x700 |
800x800 |
30 |
[10 |
1300x1700 |
1400x1800 |
50 |
[18a |
|
700x900 |
800x1000 |
1500x1100 |
1600x1200 |
||||
|
700x1100 |
800x1200 |
1500x1300 |
1600x1400 |
||||
|
900x700 |
1000x800 |
1500x1500 |
1600x1600 |
||||
|
900x900 |
1000x1000 |
1500x1700 |
1600x1800 |
||||
|
900x1100 |
1000x1200 |
1500x1900 |
1600x2000 |
||||
|
900x1300 |
1000x1400 |
30 |
[14a |
1700x1300 |
1800x1400 |
||
|
1100x700 |
1200x800 |
1700x1500 |
1800x1600 |
||||
|
1100x900 |
1200x1000 |
1700x1700 |
1800x1800 |
||||
|
1100x1100 |
1200x1200 |
1700x1900 |
1800x2000 |
||||
|
1100x1300 |
1200x1400 |
1700x2100 |
1800x2200 |
||||
|
1100x1500 |
1200x1600 |
1900x1500 |
2000x1600 |
||||
|
1300x900 |
1400x1000 |
1900x1700 |
2000x1800 |
||||
|
1300x1100 |
1400x1200 |
1900x1900 |
2000x2000 |
||||
|
1300x1300 |
1400x1400 |
1900x2100 |
2000x2200 |
||||
|
1300x1500 |
1400x1600 |
|
|
|
|
|
|
