LORD MRF-132DG fluid is a hydrocarbon-based magneto-rheological (MR) fluid bulated for general use in controllable, energy-dissipating applications such as shocks, dampers and brakes.
MRF-132DG fluid is a suspension of micron-sized, magnetizable particles in a carrier fluid. When exposed to a magnetic field, the rheology of MRF-132DG fl uid reversibly and instantaneously changes from a free-flowing liquid to a semi-solid with controllable yield strength. Altering the strength of the applied magnetic field precisely and proportionally controls the consistency or yield strength of the fluid.
MRF-132DG fluid can be used in valve mode (fluid flowing through an orifi ce) or in shear mode (fluid shearing between two surfaces). In the absence of a magnetic field, MRF-132DG fluid flows freely or allows free movement. Upon application of a magnetic field, the fluid’s particles align with the direction of the field in chain-like fashion, thereby restricting the fluid’s movement within the gap in proportion to the strength of the magnetic field.
Features and Benefits
Fast Response Time – responds instantly and reversibly to changes in a magnetic field
Dynamic Yield Strength – provides high yield strength in the presence of a magnetic field and very low yield strength in the absence of a magnetic field; allows for a wide range of controllability.
Temperature Resistant – perbs consistently throughout a broad temperature range, meeting the requirements of demanding applications such as automotive shock absorbers.
Hard Settling Resistant – provides high resistance to hard settling; easily redispersed.
Non-Abrasive – bulated to not abrade the devices in which the MR fluid is used.
LORD MRF-122EG fluid is a hydrocarbon-based magneto-rheological (MR) fluid bulated for general use in controllable, energy-dissipating applications such as shocks, dampers and brakes.
MRF-122EG fluid is a suspension of micron-sized,magnetizable particles in a carrier fluid. When exposed to a magnetic field, the rheology of MRF-122EG fluid reversibly and instantaneously changes from a free-flowing liquid to a semi-solid with controllable yield strength. Altering the strength of the applied magnetic field precisely and proportionally controls the consistency or yield strength of the fluid.
MRF-122EG fluid can be used in valve mode (fluid flowing through an orifice) or in shear mode (fluid shearing between two surfaces). In the absence of a magnetic field, MRF-122EG fluid flows freely or allows free movement. Upon application of a magnetic field, the fluid’s particles align with the direction of the field in chain-like fashion, thereby restricting the fluid’s movement within the gap in proportion to the strength of the magnetic field.
Features and Benefits
Fast Response Time – responds instantly and reversibly to changes in a magnetic field.
Dynamic Yield Strength – provides high yield strength in the presence of a magnetic field and very low yield strength in the absence of a magnetic field; allows for a wide range of controllability.
Temperature Resistant – perbs consistently throughout a broad temperature range, meeting the requirements of demanding applications such as automotive shock absorbers.
Hard Settling Resistant – provides high resistance to hard settling; easily redispersed.
Non-Abrasive – bulated to not abrade the devices in which the MR fluid is used.
