德國，意大利原裝進口電機泵閥門 流量計 油缸等配件系列產品
如果您對該產品感興趣或者需要相關產品資料，歡迎與我們聯系。
公司名稱：北京志鴻恒拓科技有限公司
聯系電話：13167366827
座機號 ：010-56016168 010-56010878
聯系人：倪經理
聯系QQ：3188689499
聯系郵箱：3188689499@qq.com
聯系地址：北京市朝陽區大望路SOHO現代城3-902
我們的優勢品牌有pep LAKOS WORTISAND REFLEX rittal elin beck
SPIROTECH ASCON PNEUMATEX Rotech Holmatro Brinkman Chr. Mayr End-Armaturen Hawe Roemheld Flowserve Vickers Jahns Rexroth Stoeber Bucher Volkmann Carl Rehfuss Dunkermotoren Steimel Gemue Knoll Kracht Kral Danfoss Bauer Abel
Speck Lammers Ac-motoren Mankenberg Moog Festo LGB
Dopag EGE Beyer Otto Kiepe HBM Hydropa Hydrotechnik
Klaschka AirCom Elobau Kuhnke Hilesheim E-T-A Senstronics
Adz Nagano Barksdale PMA Chromalox Ashcroft KFG
Haehne BEDIA Stego丨 Salzer Kobold Kistler Contrinex brinkamnn Busch BUSCK Cantoni Carl Rehfuss Katko Krah EPCOS Danotherm Micro Detectors Bender Kniel Kraus Naimer Bihl+Wiedemann Rinck Schaltbau Di-soric Ditb Dittmer Dold Diener Provertha
Fotoelektrik Pauly Kissling CEAG Fernsteuergerate(FSG) Jola Konzept Wenglor Novotechnik Megatron Releco Eckelmann Addi-Data Murr ASM丨 BERNSTEIN Conbec MEGATRON Block
Hartmann Mecheltron Saia-Burgess Mitronic JVLDeutschland
公司簡介:
瑞士KFG LEVEL是全球領先的液位測量計供應商之一。在KFG LEVEL主要產品配上磁浮開關、液位傳感器、通過液位導向，使得KFG LEVEL成為世界最大工業企業的供應商。KFG LEVEL的核心競爭力在于在極短的時間內為客戶構建起能在任何液體媒介下使用的液位測量計，無論是在餐飲業用的衛生設備,還是在北海石油平臺下使用的高壓儀器。為了能在買方市場的環境下生存，KFG LEVEL確保他們所生產的每一臺設備具有最好的品質。
公司主要產品：KFG LEVEL磁性浮球液位變送器、KFG LEVEL磁性浮球開關、KFG LEVEL磁性開關、KFG LEVEL流量控制器
KFG LEVEL磁性浮球液位變送器
原理：浮動
比重：≥400kg/m3
設計壓力：-1bar到150bar
設計溫度：-50℃到250℃
材質：不銹鋼/黃銅/鈦/合金/聚酰胺/聚氯乙烯/聚丙烯/聚偏二氯乙烯/E-CTFET涂層/PFA涂層
KFG LEVEL磁性浮球開關
原理：浮動
比重：≥400kg/m3
設計壓力：-1bar到150bar
設計溫度：-50℃到250℃
材質：不銹鋼/黃銅/鈦/合金/聚酰胺/聚氯乙烯/聚丙烯/聚偏二氯乙烯/E-CTFET涂層/PFA涂層
KFG LEVEL流量控制器
原理：浮動元素測量
粘度范圍：30cSt到600cSt
設計壓力：-1bar到300bar
設計溫度：-20℃到160℃
材質：不銹鋼/鈦/鋼聚酰胺11涂層
瑞士KFG LEVEL液位開關ALE/V/SO-V/U-L200/12-1
4M0038
型號：ALE/V/SO-V/U-L200/12-1
品牌：KFG LEVEL AG
原產國：瑞士
type:AL...,AV...,AP...,AS...,K..,-EXIA/G
SEV 11 ATEX 0188
KD-32714/1, CH-6341 Baar
030 EA4 1815 10000000 /52071
KFG LEVEL液位開關ALE/V/SO-V/U-L200/12-1
Magnetic float level switch液位開關
Magnetic float level switch KD-19772/1
TYPE: ALE/V/SO-V/U-L200/12-1/SVK44/15/A-EXIAGD
L1=160mm
Please note that the switch changeover point will be set to 160mm(L1=160mm, factory setting)
instead of original L1=147mm.
12個KFG LEVEL液位開關到貨圖片
品牌KFG LEVEL
重量2kg/pcs
KFG LEVEL液位開關ALE/V/SO-V/U-L200/12-1
KFG LEVEL液位計ALVF-80/55- VU-L197-SVK44A-Ex /D L1=147mm T6-T4
KFG LEVEL液位計pos. 1 / Magnetic float level switch KD-19772/1
type ALE/V/SO-V/U-L197/12-1/SVK44/15/A-EXIAGD
具體參數
國外報價的參數：如下
notes：
design pressure: 0 / 0.5 bar ? working pressure: 0 / 0.5 bar gravity: 800 kg/m3
design temperature: 0 / 130°C ? working temperature: 0 / 130°C ? ambient temperature: 0 /
100°C
electrical connection
ALE: housing 64 x 58 x 34 mm in aluminium with cable entry M20 x 1.5 mm / IP65
process connection
V: material quality stainless steel 1.4404 / 1.4435 / 1.4571 ( 316L & 316Ti )
SO: process connection standard oval flange 80 x 50 mm ( hole circle 55 mm / 2 x ? 6.4 mm )
guide tube
V: material quality stainless steel 1.4404 / 1.4435 / 1.4571 ( 316L & 316Ti )
12: tube outside diameter ? 12.00 mm
L [mm] / M [mm]: L = 197 mm
level contact function
U: switch function change over ( SPDT ) L1 = 147 mm
switch rating: Atex 94/9/EC Exia≤100 mA
number / of floats
1 / SVK44/15/A: stainless steel 1.4571 ( 316Ti ) / ? 44 x 52 mm / inner bore ? 15 mm
float stop: adjustable collar
approval
EXIAGD: approval Atex 94/9/EG - according to Exia, atmosphere gas and dust
adjustable collar with PTFE impact protection ring
IP66, temperature: T6 - T4 / T80°C - T100°C, zone: 21, 22
KFG LEVEL液位開關ALE/V/SO-V/U-L200/12-1
KFG LEVEL液位開關ALE/V/SO-V/U-L200/12-1
KFG LEVEL液位開關ALE/V/SO-V/U-L200/12-1
KFG LEVEL液位計ALF/TP50BF/V/K5/EXIAG-DO-M500
品名：液位計
型號：ALF/TP50BF/V/K5/EXIAG-DO-M500
品牌：KFG LEVEL
原產國：瑞士
品牌KFG LEVEL液位計ALF/TP50BF/V/K5/EXIAG-DO-M500
液位計1pcs
Bypass level transmitter
pos. 1 / Bypass level transmitter (KD-29726/1)
type ALF/TP50BF/V/K5/EXIAG-DO-M500
KFG LEVEL液位計ALF/TP50BF/V......
KFG LEVEL液位計pos. 1 / Bypass level transmitter (KD-29726/1)
type ALF/TP50BF/V/K5/EXIAG-DO-M500
SN15590p
design pressure: 0 / 0 bar ? working pressure: 0 / 0 bar ? gravity: 900 kg/m3
? design temperature: -10 / 80°C ? working temperature: -10 / 80°C ? ambient temperature: -10 / 40°C
chamber
? distance M / length L [mm]: M = 500 mm
transmitter
? ALF: housing 80 x 75 x 57 mm in aluminium with cable entry M20 x 1.5 mm / IP65
? DO: electrical connection top mounted
? TP50BF: head mounted transmitter TP5350B / 2-wire ( 9-30V DC / Foundation Fieldbus FF / IEC Ex )
? V: material quality stainless steel 1.4404 / 1.4435 / 1.4571 ( 316L & 316Ti )
? K5: measuring accuracy 5mm
? EXIAG: approval Atex 94/9/EG - according to Exia, atmosphere gas
Additional inbation:
According drawing 107932 ( Pos. 23, 24
