Pendant light fitting(NFC9180闃茬湬娉涘厜鐕�)
pendant fitting nfc9180
MATERIALS
Housing Die-casting aluminum
Transparent cover Borosilicate glass
ELECTRICAL PARAMETER
Rated voltage 220/230/240 V AC 50Hz,220 V AC 60Hz
Ambient temperature -20 o小 to +55 o小
Class of unsulation Class I
Degree of protection IP65
Cable entry G3/4
ConFORMITY TO STANDARDS
IEC60598
|
SELECTION TABLE |
|||
|
Version |
Lamp wattage |
Lamp type |
Weight |
|
NFC9180/150/MH |
150W |
MH |
5.60 kg |
|
NFC9180/70/MH |
70W |
MH |
5.20 kg |
|
NFC9180/70/HPS |
70W |
HPS |
5.20 kg |
|
|
||||||
|
Designation |
Debion |
Weight |
||||
|
Lamps |
Power |
Luminous flux |
Average life span |
Lampholder |
||
|
Lamp type |
MH |
150W |
13000lm |
10000h |
E27 |
0.10 kg |
|
70W |
5500lm |
10000h |
E27 |
0.08 kg |
||
|
HPS |
70W |
6000lm |
28500h |
E27 |
0.09 kg |
|
|
Transparentcover |
7mm temperature resistant borosilicate glass |
1.25 kg |
||||
|
Accessories for mounting |
Pendant mounting bracket |
Steel with spray coating |
0.53 kg |
|||
