| 產品參數 |
| 品牌 | MAM |
| 訂貨號 | MAM-600柴動螺桿空氣壓縮機微電腦控制器 |
| 加工定制 | 是 |
| 配件類型 | 常規配件 |
| 配件用途 | 顯示器 |
| 配件名稱 | 顯示器 |
| 適用壓縮機類型 | 螺桿式壓縮機 |
| 外形尺寸（長*寬*高） | 國標 |
| 規格 | 1 |
| 是否跨境出口專供貨源 | 否 |
| 可售賣地 | 北京;天津;河北;山西;內蒙古;遼寧;吉林;黑龍江;上海;江蘇;浙江;安徽;福建;江西;山東;河南;湖北;湖南;廣東;廣西;海南;重慶;四川;貴州;云南;西藏;陜西;甘肅;青海;寧夏;新疆 |
| 型號 | MAM-600 |
| 貨號 | MAM-600柴動螺桿空氣壓縮機微電腦控制器 MAM-600柴動空壓機控制器 | |
.jpg)
.jpg)
.jpg)
.jpg)
MAM-600型柴動空氣壓縮機控制器（以下簡稱控制器）是由高性能單片微型計算機控制的全自動柴動空氣壓縮機監控系統。采用最新型的MCU，結合先進的控制技術，能精確的檢測與顯示柴油機轉速、油壓、水溫、柴油液位、排氣壓力、排氣溫度等，并能根據用戶設定數據，對上述所測參數進行監控，發出相應的控制信號，并能通過聲光信號進行報警，提示給用戶。 歡迎各界同仁來人來電咨詢、洽談!詳細資料至公司索取。 ?企業官網：www.senpull.cn ?國內熱線：400-6969-728 ? ?技術咨詢：021-51602627??? 51602681 【進口壓縮機國際亞洲配送中心】【中國空壓機備品備件營銷中心】 ?主要技術指標 1.?????? 工作環境 ①、工作環境溫度：-30℃～ 80℃；相對濕度：≤98；抗振＞4g。 ②、振動：2～25Hz，振幅1.6mm；25～100Hz，加速度±40m/S 2 。 2.?????? 轉速測量 ①、測量范圍：0～9999rpm/min。 ②、測量誤差：≤±1rpm/min（測速齒輪在60齒以上）。 ③、最高信號頻率：50KHz。 ④、傳感器：磁阻式轉速傳感器。 3.?????? 壓力測量 ①、測量范圍：油壓0.00～1.00MPa； ②、測量精度：0.5級 ③、傳感器：HUBA高溫型4～20mA壓力傳感器。 4．排氣溫度測量 ??? ①、測量范圍：－50℃～＋150℃。 ??? ②、測量精度：0.5級. ③、傳感器：Cu50銅電阻傳感器。? 5．排氣壓力檢測，根據排氣壓力變化，產生停車信號。 6．油濾堵塞、吸油過濾器以及發電機檢測。 7．運行計時 ??? 計時范圍：0～999999小時。 8．顯示方式 ??? 0.5寸高亮數碼管顯示。 9．系統供電 ??? DC24V±30 MAM-600 type diesel driven air compressor controller (hereinafter referred to as the controller) is a fully automatic diesel dynamic monitoring system of air compressor is controlled by a high perbance single chip micro computer. Using the model of MCU, combined with the advanced control technology, can accuraby detect and display the engine speed, oil pressure, water temperature, water level, diesel exhaust pressure, exhaust temperature, and can according to the user set data, to monitor the beters measured, give out the corresponding control signals, and can alarm by sound and light signal, to b the user. Welcome people from all walks of life come to call to consult, negotiate! Details to the company for. We will be first-class products, low prices, quality service to cooperate with you, common development! The enterprise website: www.senpull.cn domestic hotline: 400-6969-728 technical consultation: 021-51602627 51602681 [imported compressor International Asia distribution center] [Chinese?air compressor spare parts marketing center] The main technical indicators 1 work environment Firstly, the working environment temperature: -30 ℃ ~ 80 ℃; relative humidity: ≤ 98; anti vibration, 4G. ②, vibration: 2 ~ 25Hz, 25 ~ 100Hz, the amplitude of 1.6mm; acceleration ± 40m/S2. 2 speed measurement ①, measuring range: 0 ~ 9999rpm/min. Second, the measurement error: ≤ ± 1rpm/min (speed gear in the 60 teeth above). The highest frequency, signal: 50KHz. ④, sensor: reluctance speed sensor. 3 pressure measurement ①, measuring range: pressure 0 ~ 1.00MPa; ②, measuring accuracy: 0.5 The sensor: HUBA, temperature 4 ~ 20mA pressure sensor. The 4 exhaust temperature measurement ①, measuring range: 50 ℃ ~ 150 C. ②, measuring accuracy: 0.5. The copper resistance sensor, sensor: Cu50. 5 the exhaust pressure detection, according to exhaust pressure change, the stop signal. 6 oil filter plugging, oil filter and generator testing. 7 run time The timing range: 0 ~ 999999 hours. 8 display mode 0.5 inch bright digital display. 9 power supply system DC24V±30 The DC24V 30
