| 產品參數(shù) | |||
|---|---|---|---|
| 品牌 | WL瓦藍科技 | ||
| 產品特性 | 電感 | ||
| 是否進口 | 否 | ||
| 產地 | 中國 | ||
| 加工定制 | 是 | ||
| 產品名稱 | 進線電抗器 | ||
| 適用范圍 | 進線 | ||
| 產品認證 | CE | ||
| 最小包裝數(shù) | 1 | ||
| 可售賣地 | 全國 | ||
| 型號 | ACL-1200 OCL-0660 | ||
?0.75KW-710KW變頻器進線電抗器制動單元剎車制動電阻濾波器
| 表1-1? ? SIEMENS直流調速器6RA24（6.3~680kW）適配的進線電抗器 | ||||||||
| 交流 | 直流 | SIEMENS，型號SIMOREG-K | 網(wǎng)側三相進線電抗器 4 | |||||
| 電源 | 功率 | |||||||
| 電壓 | kW | |||||||
| V | SIEMENS公司 | 額定 | 額定 | 額定 | SIEMENS | 瓦藍電子 | 結構號 | |
| 直流調速器訂貨號 | 電壓 | 電流 | 相電流 | 訂貨號 | 訂貨號 | No. | ||
| V | A | A | ||||||
| 3AC | 6.3 | 6RA2413-6DV62-0 | 420 | 15 | 18 | 4EP3601-8DS | ACL-0020-EISA-E1M4 | |
| 400 | 12.6-15 | 6RA2418-6DV62-0 | -485 | 30 | 25 | 4EP3701-0DS | ACL-0030-EISA-EM93 | |
| 6RA2418-6DS22-0 | ||||||||
| 25-29 | 6RA2425-6DV62-0 | 60 | 56 | 4EP3901-2DS | ACL-0060-EISA-EM47 | |||
| 6RA2425-6DS22-0 | ||||||||
| 42-44 | 6RA2430-6DC62-0 | 100 | 91 | 4EP4002-3DS | ACL-0120-EISA-EM23 | |||
| 6RA2428-6DS22-0 | -90 | -80 | （4EP4000-1DB ? ） | |||||
| 59-61 | 6RA2432-6DV62-0 | 140 | 125 | 4EU2521-0AA00 | ACL-0150-EISA-EM19 | |||
| 6RA2431-6DS22-0 | -125 | -112 | （4EU2421-1AA10） | |||||
| 84-91 | 6RA2475-6DC62-0 | 200 | 180 | 4EU2721-0AA10 | ACL-0200-EISA-EM14 | |||
| 6RA2475-6DS22-0 | ||||||||
| 105-121 | 6RA2477-6DV62-0 | 250 | 224 | 4EU2721-2AA00 | ACL-0250-EISA-EM11 | |||
| 6RA2477-6DS22-0 | ||||||||
| 168-194 | 6RA2481-6DV62-0 | 400 | 355 | 4EU3021-1AA00 | ACL-0390-EISA-E72U | |||
| 6RA2481-6DS22-0 | ||||||||
| 252-291 | 6RA2485-6DV62-0 | 600 | 500 | 4EU3621-0AA00 | ACL-0600-EISA-E53U | |||
| 6RA2485-6DS22-0 | ||||||||
| 357-412 | 6RA2487-4DV62-0 | 850 | 710 | 4EU3621-3AA00 | ACL-0800-EISA-E35U | |||
| 6RA2487-4DS22-0 | ||||||||
| 504-582 | 6RA2491-4DV62-0 | 1200 | 1000 | 4EU3921-1AA00 | ACL-01200-EISA-E35U | |||
| 6RA2491-4DS22-0 | ||||||||
| 3AC | 16-18 | 6RA2418-6GV62-0 | 30 | 25 | 4EP3700-1DS | ACL-0030-EISA-E1M8 | ||
| 500 | 6RA2418-6GS22-0 | |||||||
| 31-36 | 6RA2425-6GV62-0 | 60 | 56 | 4EP4002-0DS | ACL-0060-EISA-EM94 | |||
| 6RA2425-6GS22-0 | ||||||||
| 52-54 | 6RA2430-6GV62-0 | 100 | 91 | 4EU2421-3AA00 | ACL-0120-EISA-EM46 | |||
| 6RA2428-6GS22-0 | -90 | -80 | （4EU2421-2AA00） | |||||
| 73-75 | 6RA2432-6GV62-0 | 140 | 125 | 4EU2521-5AA00 | ACL-0150-EISA-EM38 | |||
| 6RA2431-6GS22-0 | -125 | -112 | （4EU2521-4AA00） | |||||
| 104-120 | 6RA2475-6GV62-0 | 200 | 180 | 4EU2721-6AA00 | ACL-0200-EISA-EM16 | |||
| 6RA2475-6GS22-0 | ||||||||
| 130-150 | 6RA2477-6GV62-0 | 250 | 224 | 4EU2721-8AA00 | ACL-0250-EISA-EM13 | |||
| 6RA2477-6GS22-0 | ||||||||
