| モデル |
EIA 1/3型
|
EIA 1/3型 高感度モデル |
EIA 1/2型
|
EIA 1/2型 高感度モデル |
CCIR 1/3型
|
CCIR 1/3型 高感度モデル |
CCIR 1/2型
|
CCIR 1/2型 高感度モデル |
|---|---|---|---|---|---|---|---|---|
| 型番 |
STC-E43A
|
STC-HE43A
|
STC-E42A
|
STC-HE42A
|
STC-C43A
|
STC-HC43A
|
STC-C42A
|
STC-HC42A
|
| 撮像方式 |
EIA
|
CCIR
|
||||||
| 解像度（Pixel） |
768 × 494
|
752 × 582
|
||||||
| センサーサイズ（型） |
1/3
|
1/2
|
1/3
|
1/2
|
||||
| セルサイズ H × V（μm） |
7.4 × 6.35μm
|
9.8 × 8.4μm
|
6.25 × 6.5μm
|
8.3 × 8.6μm
|
||||
| 撮像面積 H × V × D（mm） |
3.6 × 4.8 × 6
|
4.8 × 6.4 × 8
|
3.6 × 4.8 × 6
|
4.8 × 6.4 × 8
|
||||
| センサー型番 |
ICX408AL
|
ICX258AL
|
ICX418AL
|
ICX428AL
|
ICX409AL
|
ICX259AL
|
ICX419AL
|
ICX429AL
|
| 映像階調 | 2:1インターレース |
|---|---|
| 映像出力 | VBS 1.0Vp-p 75Ω、DCカップリング（0V） |
| 露光時間 | １フレーム期間、1/100,000 ～ 1/60秒（EIAモデル）/ 1/50秒（CCIRモデル）（背面DIPスイッチ / 通信により変更） |
| 通信機能 | RS232準拠（12ピンコネクタ経由）（通信ケーブル：JIG-RS232-HCA） |
| レンズマウント | Cマウント |
| 光學フィルター | 赤外線カットフィルター無し |
| 電源 | 10.8 ～ 13.2VDC 1.8W以下 |
| 外形寸法、重量 | 28(W)×28(H)×40(D)mm＊コネクタ部含まず、約43g |
