現貨Schneider交流接觸器LC1D09M7C全新正品
產品系列
TeSys
產品名稱
D
產品類型
接觸器
產品短名
LC1D
接觸器應用領域
應用于功率因數大于等于0.95的交流負載中
應用于接通分?jǐn)嗾?dòng)的鼠籠電機
使用類別
AC-4
AC-1
AC-3
極數
3P
power pole contact comb
3 NO
額定工作電流 [Ie]
25 A (at <60 °C) at <= 440 V AC AC-1 for power circuit
9 A (at <60 °C) at <= 440 V AC AC-3 for power circuit
控制回路電壓
220 V AC 50/60 Hz
輔助觸點類型
1 NO + 1 NC
補充信息
額定工作電壓 [Ue]
Power circuit: <= 690 V AC 25...400 Hz
電源回路: <= 225 V DC
電動機功率 (kW)
5.5 kW at 500 V AC 50/60 Hz (AC-3)
2.2 kW 在…上 220/240 V AC 50/60 Hz (AC-3)
4 kW 在…上 380/400 V AC 50/60 Hz (AC-3)
4 kW 在…上 415/440 V AC 50/60 Hz (AC-3)
5.5 kW 在…上 660/690 V AC 50/60 Hz (AC-3)
2.2 kW 在…上 400 V AC 50/60 Hz (AC-4)
電氣壽命
0.6 Mcycles 25 A AC-1 at Ue <= 440 V
2 Mcycles 9 A AC-3 at Ue <= 440 V
2 Mcycles 6.6 A AC-3 at Ue 660/690 V
機械壽命
15 Mcycles
操作頻率
3600 cyc/h 60 °C
動作時間
12...22 ms closing
4...19 ms opening
控制電壓限額
Drop-out: 0.3...0.6 Uc at 50/60 Hz (at <60 °C)
Operational: 0.8...1.1 Uc at 50 Hz (at <60 °C)
Operational: 0.85...1.1 Uc at 60 Hz (at <60 °C)
(~50Hz保持)功耗 (VA)
7.5 VA 60 Hz cos phi 0.3 (at 20 °C)
7 VA 50 Hz cos phi 0.3 (at 20 °C)
約定發熱電流 [Ith]
25 A (at 60 °C) for power circuit
10 A (at 60 °C) for signalling circuit
平均阻抗
2.5 mOhm - Ith 25 A 50 Hz for power circuit
熱消散
2…3 W at 50/60 Hz
額定短時耐受電流 [Icw]
105 A 40 °C - 10 s for power circuit
210 A 40 °C - 1 s for power circuit
30 A 40 °C - 10 min for power circuit
61 A 40 °C - 1 min for power circuit
100 A - 1 s for signalling circuit
120 A - 500 ms for signalling circuit
140 A - 100 ms for signalling circuit
與繼電器配合使用的熔絲
10 A gG for signalling circuit conbing to IEC 60947-5-1
25 A gG at <= 690 V coordination type 1 for power circuit
20 A gG at <= 690 V coordination type 2 for power circuit
過電壓類別
III
額定絕緣電壓 [Ui]
Power circuit: 690 V conbing to IEC 60947-4-1
Signalling circuit: 690 V conbing to IEC 60947-1
浪涌抑制模塊
無內置浪涌抑制模塊
輔助觸點類型
type mechanically bed 1 NO + 1 NC conbing to IEC 60947-5-1
type mirror contact 1 NC conbing to IEC 60947-4-1
信號回路頻率
25...400 Hz
最小開關電流 [Imin]
5 mA for signalling circuit
不重迭時間
1.5 ms on de-energisation between NC and NO contact
1.5 ms on energisation between NC and NO contact
絕緣電阻
> 10 MOhm for signalling circuit
安裝方式
導軌安裝
底板安裝
接線能力
Power circuit: screw clamp terminals 1 1…4 mm2 - external diameter: 8 mm - cable stiffness: flexible without cable end
Power circuit: screw clamp terminals 2 1…4 mm2 - external diameter: 8 mm - cable stiffness: flexible without cable end
Power circuit: screw clamp terminals 1 1…4 mm2 - external diameter: 8 mm - cable stiffness: flexible with cable end
Power circuit: screw clamp terminals 2 1…2.5 mm2 - external diameter: 8 mm - cable stiffness: flexible with cable end
Power circuit: screw clamp terminals 1 1…4 mm2 - external diameter: 8 mm - cable stiffness: solid without cable end
Power circuit: screw clamp terminals 2 1…4 mm2 - external diameter: 8 mm - cable stiffness: solid without cable end
Control circuit: screw clamp terminals 1 1…4 mm2 - cable stiffness: flexible without cable end
Control circuit: screw clamp terminals 2 1…4 mm2 - cable stiffness: flexible without cable end
Control circuit: screw clamp terminals 1 1…4 mm2 - cable stiffness: flexible with cable end
Control circuit: screw clamp terminals 2 1…2.5 mm2 - cable stiffness: flexible with cable end
Control circuit: screw clamp terminals 1 1…4 mm2 - cable stiffness: solid without cable end
Control circuit: screw clamp terminals 2 1…4 mm2 - cable stiffness: solid without cable end
電源回路: 螺釘連接
緊固扭矩
Power circuit: 1.7 N.m - on screw clamp terminals - with screwdriver flat ? 6 mm
Power circuit: 1.7 N.m - on screw clamp terminals - with screwdriver Philips No 2
控制回路: 1.7 N.m 通過 螺栓緊固 用螺絲刀 ? 6 平口
控制回路: 1.7 N.m 通過 螺栓緊固 用螺絲刀 No 2 十字螺絲
電源回路: 1.7 N.m 通過 電纜連接器 用螺絲刀 ? 6 平口 螺絲: M3.5
電源回路: 1.7 N.m 通過 電纜連接器 用螺絲刀 No 2 十字螺絲 螺絲: M3.5
高度
77 mm
寬度
45 mm
深度
86 mm
控制回路特性
AC at 50/60 Hz
額定沖擊耐受電壓 [Uimp]
6 kV conbing to IEC 60947
safety cover
無
(~50Hz吸合)功耗 (VA)
70 VA 60 Hz cos phi 0.75 (at 20 °C)
70 VA 50 Hz cos phi 0.75 (at 20 °C)
產品凈重
0.32 kg
接觸器兼容特性
M2
型號
LC1D
環境
符合標準
IEC 60947-4-1
GB 14048.4
產品認證
CCC
污染等級
3
防護措施
TH conbing to IEC 60068-2-30
IP 保護等級
IP2x 前面板 主回路適用 符合 IEC 60529
IP2x 前面板 線圈回路適用 符合 IEC 60529
運行溫度
-40…60 °C
貯存環境溫度
-60…80 °C
周?chē)諝鉁囟?nbsp;
60…70 °C （Uc下允許）
工作海拔
3000 m without derating
耐火及耐異常高溫能力
850 °C conbing to IEC 60695-2-11
抗沖擊、震動性能
抗震性能 觸頭打開 (2 gn (5...300 Hz)) 符合 IEC 60068-2-6
抗震性能 觸頭閉合狀態 (4 gn (5...300 Hz)) 符合 IEC 60068-2-6
抗沖擊性能 11 ms 觸頭打開 (10 gn) 符合 IEC 60068-2-27
抗沖擊性能 11 ms 觸頭閉合狀態 (15 gn) 符合 IEC 60068-2-27
質量標識
CE 聲明
Packing Units
包裝1的單位類別
PCE
個/公斤
1
包裝重量
360.78 g
包裝1高度
5.03 cm
包裝1寬度
7.83 cm
包裝1長度
9.27 cm
