| 洛氏標尺(Rockwell Scales) | HRA, HRB, HRC, HRD, HRE, HRF,HRG,HRH,HRK |
| 初試驗力（Initial Testing Force） | 10Kg(98.07N) |
| 試驗力（All Testing Force） | 60Kg (588N), 100Kg (980N), 150Kg (1471N) |
| 硬度讀取 (Indication of Hardness Value) | 表盤式（Dial ） |
| 試件最大高度 Max. Height of Specimen | 170mm |
| 儀器尺寸(Overall Dimension) | 520X240X700MM (長X寬X高, LXWXH) |
| 儀器重量(Net Weight) | 80 Kg |
| 執(zhí)行標準 (Carried Standard) | GB/T230.2 國家標準、JJG112檢定規(guī)程 GB/T230.2 Chinese Standard and JJG112 Inspection Rule |
| 標準配件、附件 (Standard Accessories) | 金剛石洛氏壓頭，直徑1.5875mm硬質(zhì)合金球壓頭，大平試臺、中平試臺、V型試臺，硬度塊 Diamond Rockwell Indenter, Diameter 1.5875mm Hard Alloy Steel Ball Indenter, Large Testing Table , Medium Testing Table and V-shaped Testing Table, HRC and HRB Hardness Blocks
|
