| LYC 32212C | |
| 內徑, d | 60 (0/-0.008) mm |
| 外徑, D | 110 (0/-0.011) mm |
| 寬度, B (or T) | 29.75 (0.2/0) mm |
| Cone 寬度, B | 28 mm |
| Cup 寬度, C | 22 mm |
| Cone 倒角, r | 2 mm |
| Cup 倒角, r | 1.5 mm |
| Effective Load Center, a | 28.8 mm |
| 動負荷, Cr | 105000 N |
| 靜負荷, C0r | 130000 N |
| 極限轉速（油脂） | 3200 RPM |
| 極限轉速（油） | 4500 RPM |
| Cage Material | Pressed Steel |
| da min | 72 mm |
| db max | 68 mm |
| Da max | 101 mm |
| Da min | 92 mm |
| Db min | 106 mm |
| Sa min | 4 mm |
| Sb min | 7.5 mm |
| Shaft ra max | 1.5 mm |
| Housing ra max | 1.5 mm |
| 重量 | 1.11 kg |
