河南省鄭州反吹風布袋除塵器 脈沖袋式除塵設備—廠家博世通用：13949123660
DFC、GFC、TFC型反吹風布袋除塵器簡介：
DFC、GFC、TFC型反吹風布袋除塵器是分室循環(huán)反吹清灰。下進風、內濾式高效除塵器。DFC、GFC、TFC型反吹風布袋除塵器適用于冶金、化工、建材、電力、糧食加工、機械等部門以及工業(yè)爐窯或鍋爐，作為凈化含塵濃度。
DFC、GFC、TFC型反吹風布袋除塵器技術性能：
| 型號 | 濾袋數(shù)量(個) | 過濾面積(m2) | 過濾風速(米／分) | 風量(m3/h) | 阻力(Pa) | 外型尺寸(長?寬?高)(m) | 重量(t) | |
| 正壓式 | TFC-5200 | 529 | 5200 | ＜1.0 | 312000 | 180-200 | 16.05?8.2?26.3 | 170 |
| TFC-7800 | 888 | 7800 | 468000 | 23.85?8.2?26.3 | 240 | |||
| TFC-10400 | 1184 | 10400 | 624000 | 16.05?16.4?26.3 | 310 | |||
| TFC-13000 | 1480 | 13000 | 780000 | 23.85?16.4?26.4 | 380 | |||
| TFC-15600 | 1776 | 15600 | 936000 | 31.65?16.4?26.3 | 450 | |||
| 負壓式 | TFC-4000 | 448 | 4000 | 240000 | 11.1?15.6?24.8 | 240 | ||
| TFC-6000 | 672 | 6000 | 360000 | 15.65?15.6?24.8 | 240 | |||
| TFC-8000 | 860 | 8000 | 480000 | 20.2?15.6?24.8 | 320 | |||
| TFC-10000 | 1120 | 10000 | 600000 | 24.7?15.6?24.8 | 400 | |||
| TFC-12000 | 1344 | 12000 | 720000 | 29.25?15.6?24.8 | 480 | |||
| GFC-280-4 | 336 | 1120 | 67200 | 7.64?3.647?15.31 | 38.8 | |||
| GFC-280-5 | 420 | 1400 | 84000 | 9.58?3.647?15.30 | 42 | |||
| GFC-280-6 | 504 | 1680 | 100800 | 11.52?3.647?15.16 | 50.26 | |||
| GFC-280-8 | 672 | 2240 | 134400 | 7.64?7.29?15.36 | 63.98 | |||
| GFC-280-10 | 840 | 2800 | 168000 | 9.58?7.29?15.36 | 72.12 | |||
| GFC-280-12 | 1008 | 3360 | 201600 | 11.52?7.29?15.34 | 81.68 | |||
| GFC-230-4 | 264 | 920 | 55200 | 7.64?3.05?15.08 | 36.4 | |||
| GFC-230-5 | 330 | 1150 | 69000 | 9.58?3.05?15.08 | 47.2 | |||
| GFC-230-6 | 396 | 1380 | 82800 | 11.53?3.05?15.8 | 54 | |||
| GFC-230-8 | 528 | 1340 | 110400 | 7.64?5.9?15.08 | 61.2 | |||
| GFC-230-10 | 660 | 2300 | 138000 | 9.58?5.9?15.08 | 67.4 | |||
| GFC-230-12 | 792 | 2760 | 165600 | 11.52?5.9?15.08 | 74.9 | |||
| GFC-140-4 | 160 | 560 | 33600 | 3.75?3.53?15.16 | 25 | |||
| GFC-140-6 | 240 | 840 | 50400 | 5.70?3.53?15.16 | 38 | |||
| GFC-140-8 | 280 | 1120 | 67200 | 7.64?3.53?15.16 | 50.7 | |||
| GFC-140-10 | 320 | 1400 | 8400 | 9.58?3.53?15.16 | 63 | |||
| GFC-140-12 | 480 | 1680 | 100800 | 11.52?3.53?15.16 | 75.7 | |||
| GFC-83-6 | 144 | 498 | 29880 | 4.3?3.5?13.9 | 23.0 | |||
| GFC-83-8 | 192 | 664 | 39840 | 5.64?3.5?13.9 | 30.7 | |||
| GFC-83-10 | 240 | 830 | 49800 | 7.1?3.5?13.9 | 38.4 | |||
| GFC-83-12 | 288 | 996 | 59760 | 11.5?3.5?13.9 | 47.3 | |||
| DFC-6-524 | 152 | 524 | 31400 | ф4000?16140 | 18 | |||
| DFC-3-180 | 52 | 180 | 10800 | ф2340?12480 | 10.86 | |||
| DFC-3-126 | 52 | 126 | 7560 | ф2340?10680 | 9.66 | |||
| DFC-3-80 | 52 | 80 | 4800 | ф2340?9030 | 8.08 | |||
| DFC-2-103 | 30 | 103 | 6180 | ф1808?11406 | 6.1 | |||
| DFC-2-73 | 30 | 73 | 4380 | ф1818?9606 | 5.4 | |||
| DFC-2-45 | 30 | 45 | 2700 | ф1818?7905 | 4.5 | |||
