burkert 8110液位開關寶帝8110 The 8110 is a vibrating level switch for liquids, using a tuning fork for level detection. burkert 8110液位開關寶帝8110 It is designed for industrial use in areas of process technology and can be used in liquids. Typical applications are overfill or dry run protection. burkert 8110液位開關寶帝8110 The small tuning fork (40 mm of length) allows the use in vessels, tanks and pipes.
銷售人員：李超
聯系方式：021-61552611/13371929516
詢價qq：1015677290
burkert 8110液位開關寶帝8110參數
burkert 8110 Materials
Tuning fork and fitting
burkert 8110 Process seal / Housing
burkert 8110 Stainless steel 316L (1.4435)
Klingersil® C 4400/ Stainless steel 316L and plastic PEI
burkert 8110 Weight Approx. 250 g
burkert 8110 Electrical connections Cable plug acc. to EN 175301-803 or M12 x 1 male
fixed connector
burkert 8110液位開關寶帝8110
burkert 8110 Process fitting Thread G or NPT, 1/2”, 3/4” or 1”; clamp 2”
Surface finishing quality Ra < 3.2 m (thread) / Ra < 0.8 m (Clamp)
burkert 8110 Dynamic viscosity / Density 0.1...10000 mPa.s / 0.7...2.5 g/cm3
burkert 8110 Medium temperature -40...+100°C (150°C for Clamp process connection)
burkert 8110 Medium pressure -1...64 bar
Accuracy
Hysteresis
burkert 8110 Delay time / Frequency
burkert 8110 Approx. 2 mm with vertical installation
burkert 8110 Approx. 500 ms / Approx. 1200 Hz
burkert 8110 Output Transistor output PNP or contactless electronic switch
burkert 8110液位開關寶帝8110
burkert 8110 Electrical data - Sensor with PNP transistor output
burkert 8110 Power supply / power consumption 10...35 V DC / max. 0.5 W
burkert 8110 Load current Max. 250 mA (output - overload and permanently short circuit proof)
burkert 8110 Voltage loss Max. 3 V DC
burkert 8110 Turn-on voltage Max. 34 V DC
burkert 8110 Blocking current <10 µA
burkert 8110 Mode Min./max changeover by electrical connection
burkert 8110 Max.: overfill protection - Min.: dry run protection
burkert 8110 LED indication: green and red
burkert 8110液位開關寶帝8110
burkert 8110 Electrical data - Sensor with contactless electronic switch output
burkert 8110 Power supply 20...253 V AC, 50/60 Hz or 20...253 V DC
Domestic current requirement Approx. 3 mA (via the load circuit) (Not with PLC)
burkert 8110 Load current Min. 10 mA - Max. 250 mA
burkert 8110 Mode Min./max changeover by electrical connection
Max.: overfill protection - Min.: dry run protection
