代理burkert 8323壓力傳感器寶帝8323壓力變送器This pressure transmitter is designed to cover the majority of industrial applications in the field of industrial pressure measurement technology.代理burkert 8323壓力傳感器寶帝8323壓力變送器High accuracy, compact design, robust construction and flexibility make this instrument universal and suitable for different measurement functions.代理burkert 8323壓力傳感器寶帝8323壓力變送器For technical reasons piezoresistive sensor element is used for measuring ranges up to 16 bar and thin film sensor element for the measuring range of 25 bar.代理burkert 8323壓力傳感器寶帝8323壓力變送器Wetted parts are made of stainless steel and completely welded.代理burkert 8323壓力傳感器寶帝8323壓力變送器Internal seal elements, which could restrict the choice of measuring materials, are excluded.
銷售人員：李超
聯(lián)系方式：021-61552611
詢價qq：1015677290
代理burkert 8323壓力傳感器寶帝8323壓力變送器參數(shù)：
burkert 8323Electrical connections 4 pin cable plug according to EN 175301-803
burkert 8323Measuring range (Pressure reference
= relative pressure [atmospheric])
0 up to 0.1; 0.16; 0.25; 0.4; 0.6; 1.0; 1.6; 2.5; 4.0; 6.0;
10.0; 16.0 or 25.0 bar (in PSI on request)
burkert 8323Measuring element piezo (≤ 16 bar) / thin film (25 bar)
Fluid temperature
Standard version
burkert 8323Standard Flush Diaphragm version
代理burkert 8323壓力傳感器寶帝8323壓力變送器
burkert 8323EHEDG Flush Diaphragm version
-20 up to +100°C (-4 to 212 °F)
-30 up to +100°C (-22 to 212 °F)
-20 up to +150°C (-4 to 302 °F)
burkert 8323Compensated T° range 0 up to +80°C (32 to 176 °F)
burkert 8323Temperature coefficient
Average Tc of zero
burkert 8323Standard version
Flush Diaphragm version
Average Tc of Span
in compensated T° range
≤ 0.2% of F.S.* / 10K
≤ -0.2...+0.3% of F.S.* / 10K
≤ 0.2% of F.S.* / 10K
代理burkert 8323壓力傳感器寶帝8323壓力變送器
burkert 8323Accuracy ≤ 0.5% of F.S.* (2-point calibration)1)
≤ 0.25% of F.S.* (Best fit calibration, BFSL)1)
Hysteresis ≤ 0.1% of F.S.*
burkert 8323Repeatability ≤ 0.05% of F.S.*
burkert 83231-year stability ≤ 0.2% of F.S.* (at reference conditions)
代理burkert 8323壓力傳感器寶帝8323壓力變送器
代理burkert 8323壓力傳感器寶帝8323壓力變送器
