全新原裝burkert 2873比例調節閥 The direct-acting solenoid control valve Type 2873 (32mm installation width) is used as the regulating unit in control loops. 全新原裝burkert 2873比例調節閥 Due to an elastomeric seat seal the valve closes tight (integrated shut-off function), up to the DN specifi c nominal pressure, see ordering chart on page 3.
銷售人員：李超
聯系方式：021-61552611/13371929516
詢價qq：1015677290
全新原裝burkert 2873比例調節閥特點：
全新原裝burkert 2873比例調節閥參數：
burkert 2873 Body material Brass, stainless steel
burkert 2873 Seal material FKM, EPDM on request
burkert 2873 Medium Neutral gases, liquids on request
burkert 2873 Pressure range 0 ... 16 bar 2)burkert 2873 Medium temperature -10 ... +90 °C
burkert 2873 Ambient temperature max. +55 °C
全新原裝burkert 2873比例調節閥
burkert 2873 Power supply 24 V DCPWM frequency 1200 Hz
burkert 2873 Power consumption 9 W
Max. coil current 3) 420 mA
burkert 2873 Duty cycle 100 % continuously rated
burkert 2873 Port connection Sub-base, G 1/8, G 1/4, NPT 1/8, NPT 1/4,
further on request
全新原裝burkert 2873比例調節閥
burkert 2873 Electrical connection Cable plug Type 2508 according to DIN EN 175301-803, industrial standard Form A
burkert 2873 Installation As required, preferably with actuator in upright position
全新原裝burkert 2873比例調節閥
全新原裝burkert 2873比例調節閥
