burkert 3230用于污水處理介質氣動塑料隔膜閥 Plastic 2-way diaphragm valve is controlled with a single acting pneumatic actuator. Used for water and products, contaminated fluids.

銷售聯系人：李超

聯系方式：021-61552611/13371929516

qq：1015677290

burkert 3230用于污水處理介質氣動塑料隔膜閥具體功能（標準）：

1. 行程限制
2. 光學位置指示器
3. 簡單的轉換功能
4. 污染的液體

burkert 3230用于污水處理介質氣動塑料隔膜閥特點：

1. 控制功能可改裝
2. 適用侵蝕性介質
3. 套頭外殼結構
4. 緊湊型結構

burkert 3230用于污水處理介質氣動塑料隔膜閥參數：

burkert 3230 DN 12 and 15 diameter

burkert 3230 Material PVC-U body, PP

burkert 3230 Material EPDM

burkert 3230 Material of the actuator PP, reinforced fiberglass

Neutral or aggressive fluids fluids compatible with

burkert 3230 body materials and joints

Fluid temperature See chart next page

burkert 3230用于污水處理介質氣動塑料隔膜閥

burkert 3230 Ambient temperature 0 to + 60 ° C

Steering fluid lubricated compressed air / oil-free and fluids

neutral (eg water)

burkert 3230 Steering pressure Max. 7 bar, see chart next page

Bolting Connection Ø16, threaded G 3/8

Union fitting Ø20

burkert 3230 Mounting position indifferent position, preferably with actuator up

burkert 3230用于污水處理介質氣動塑料隔膜閥

burkert 3230用于污水處理介質氣動塑料隔膜閥
