burkert 6525德國采購寶德6525電磁閥 The Type 6525 consist of a pilot flipper valve Type 6144 and a pneumatic seat valve. burkert 6525德國采購寶德6525電磁閥 The flipper principle allows switching of high pressures together with low power consumption and fast response times. burkert 6525德國采購寶德6525電磁閥 All valves are equipped with manual override as a standard. burkert 6525德國采購寶德6525電磁閥 The valve is also available with a second connection (pressed cable), whereby a safety-related shut-off function is realized
銷售人員：李超
聯(lián)系方式：021-61552611
qq：1015677290
burkert 6525德國采購寶德6525電磁閥特點：
burkert 6525德國采購寶德6525電磁閥參數(shù)：
Orifice DN4,0
burkert 6525電磁閥 Body material PPS, PA
Seal material FKM, NBR and PUR
Medium Lubricated, oil free, dry compressed air; neutral gases
(5 µm filter recommended)
burkert 6525電磁閥 Medium temperature -10...+50°C
Ambient temperature -10...+55°C
Manual override Standard
burkert 6525德國采購寶德6525電磁閥
Port connection Flange for MP11
Pneumatic module Type MP11 with M5, M7, push-in connection Ø 6 mm
burkert 6525電磁閥 Voltage tolerance ±10%
Cycling rate approx. 1000 c.p.m.
burkert 6525電磁閥 Voltage 24 V DC *
burkert 6525電磁閥 Nominal power 0.8 W
burkert 6525電磁閥 Duty cycle Continuous operation (100% ED)
burkert 6525德國采購寶德6525電磁閥
Electrical connection
on valve
Rectangular plug with
Raster 5.08 mm
Type of protection IP40 with rectangular plug
Protection class 3 acc. to VDE 0580
burkert 6525電磁閥 Weight 21 g
Mounting with 2 screws M2 x 20
Installation As required, preferably with actuator upright
burkert 6525德國采購寶德6525電磁閥
