burkert 6516/6517系列 EExi C-D-H電磁閥 valves are used for process actuation in hazardous areas. burkert 6516/6517系列 EExi C-D-H電磁閥 Thanks to the intrinsically safe design and the possibility of block mounting, burkert 6516/6517系列 EExi C-D-H電磁閥 the valves can be used in a wide variety of demanding applications.
銷售人員：李超
聯(lián)系方式：021-61552611/13371929516
qq：1015677290
burkert 6516/6517系列 EExi C-D-H電磁閥參數(shù)：
Nominal voltage 24 V/DC
(for further information also consult our
data sheet „Recommended Barriers“)
Duty cycle 100% continuously rated
Protection class IP 65 with cable plug
burkert 6516/6517系列 EExi C-D-H電磁閥
Materials
Body PA
Threaded port material Brass or stainless steel
Seal PB (NBR and PUR)
Fluids Lubricated or unlubricated
compressed air, instrument air
burkert 6516/6517系列 EExi C-D-H電磁閥
and nitrogen
Ambient temperatures
Block assembly -10 up to +50°C (T6)
-10 up to +55°C (T5)
Single mounting -10 up to +55°C (T6)
Mounting position Any, preferably solenoid
system upright
burkert 6516/6517系列 EExi C-D-H電磁閥
