burkert 6511 H 2.5電磁閥
發布者：lichao888  發布時間：2016-01-18 16:50:30
burkert 6511 H 2.5電磁閥 Type 6511 consists of the pilot fl ipper solenoid valve Type 6144 and a pneumatic seat valve. the Flipper principle allows switching of high pressures with low power consumption and with short switching times. burkert 6511 H 2.5電磁閥 All valves are equipped with manual override as a standard. burkert 6511 H 2.5電磁閥 Type 6511 is extendable and preferably with a cable plug at the back of the valve island, Type 8640, and with the plug connection at the front of the valve block in the pneumatic control actuators.

銷售人員：李超

聯系方式：021-61552611/13371929516

qq：1015677290

burkert 6511 H 2.5電磁閥特點：

  1. 緊湊型設計
  2. 單和歧管安裝
  3. 低功耗
  4. 快速響應時間

burkert 6511 H 2.5電磁閥參數：

Orifi ce DN 2.5 mm

Body material PPS, PA

Seal material NBR, FKM

Medium Lubricated, oilfree, dry compressed air; Neutral gases

(5μm fi lter recommended) burkert 6511 H 2.5電磁閥

Medium temperature 0 to +50 °C

Ambient temperature 0 to +55 °C

Manual override Standard

Port connection Flange for MP02 burkert 6511 H 2.5電磁閥

Pneumatic module Type MP02 with M5 or push-in connection Ø4 mm

Voltage tolerance ±10%

Operating voltages 24 V DC

Nominal power 0.8 W burkert 6511 H 2.5電磁閥

Duty cycle Continuous operation (100% ED)

Electr. connection on valve Rectangular plug, 2 pin, with raster 5.08 mm

Protection class IP 40

Protection class 3 acc. to VDE 0580 burkert 6511 H 2.5電磁閥

Mounting with 2 self tapping screws for plastic 2 x 20

Installation As required, preferably with actuator upright

burkert 6511 H 2.5電磁閥



burkert 6511 H 2.5電磁閥
